DataMan 380 – Barcode Reader
DataMan 380 is an industrial image-based barcode reader with integrated AI, delivering fast and accurate performance for high-speed manufacturing and logistics applications.
With a wide field of view, automatic focusing, and advanced decoding technology, the device helps reduce errors, save installation space, and optimize operational efficiency.
DataMan 380 is an image-based barcode reader capable of capturing and tracking product and parcel information in high-speed applications, providing detailed and valuable analytical data to support operational processes.
BENEFITS OF DATAMAN 380
- Increase processing speed: Powerful AI-assisted decoding technology boosts throughput, especially in applications reading multiple code types
- Reduce errors and rework: A wide field of view allows more details to be captured in a single scan, while advanced imaging technology delivers clear images even in complex environments, ensuring stable and accurate reading
- Simplify installation and deployment: With a large FoV, a single DataMan 380 can replace multiple traditional readers, saving space, installation time, and integration costs
TECHNICAL SPECIFICATIONS OF DATAMAN 380
| DataMan 380 | |
| Type of lens | C-Mount or Cognex high-speed liquid lens with autofocus capability |
| Status indicators | Pass/Fail lights and status LED ring, Network LED, and Error LED |
| Power consumption | 24 VDC ± 10% (LPS or NEC Class 2)
No USB: – Average ≤ 15 W (illumination off) – Average ≤ 40 W (with illumination) – Peak ≤ 2 A |
| Material | Die-cast and extruded aluminum housing |
| Weight | DataMan 380 without accessories: 775 g (27.3 oz) |
| OperatingTemperature | 0°C to 40°C (32°F – 122°F) |
| Storage Temperature | -20°C to 80°C (-4°F – 176°F) |
| Humidity | < 95% Non-condensing |
CONTACT US TODAY FOR OPTIMAL BARCODE SCANNING SOLUTIONS CONSULTATION
Contact us today for detailed consultation on the DataMan 380 barcode reader solution best suited for your factory.
