Barcode Verification System – DataMan 8072 Series
DataMan 8072 Series is a high-performance industrial barcode reader designed for demanding manufacturing environments. The device integrates multi-angle lighting and a high-resolution camera, enabling reliable image capture in challenging conditions.
Advanced decoding algorithms accurately read complex DPM codes, even on metal, curved, or highly reflective surfaces.
The DataMan 8072 Series barcode verification system is equipped with powerful multi-angle lighting, advanced decoding algorithms, a high-speed processor, and a high-resolution camera. This enables accurate reading and verification of even the most challenging Direct Part Marking (DPM) codes on complex surfaces such as metal, curved, or highly reflective materials, ensuring reliable performance in demanding industrial environments.
FEATURES OF DATAMAN 8072
DataMan 8072 is the only device equipped with a complete multi-angle lighting system at 30°, 45°, and 90°, combined with advanced decoding algorithms, a high-speed processor, and a high-resolution camera. This enables accurate reading and verification of DPM codes on metal, curved, or reflective surfaces, fully compliant with ISO/IEC TR 29158 (AIM DPM) standards.
When combined with the DataMan Setup Tool software, the system delivers detailed, stable, and repeatable analysis results, while generating clear inspection reports to verify code compliance and detect printing defects or process deviations.
With a compact handheld design, IP65 protection, impact resistance, and stable operation in harsh environments, DataMan 8072 is a flexible, accurate, and durable barcode verification solution for all industrial applications.
TECHNICAL SPECIFICATIONS OF DATAMAN 8072 SERIES
| DataMan 8072V | DataMan 8072V HD | |
| Image Sensor | 1.2 MP | |
| Illumination System | Three selectable illumination angles: 30°, 45°, and 90° | |
| Communication Protocols | USB và Ethernet | |
| Power Supply | USB: 6V and 1.0A
Ethernet: PoE Class 2 power supply |
|
| Weight | 572g (no cable) | |
| Standards & Certifications | CE Certification | |
CONTACT US TODAY FOR CONSULTATION
Contact ETEK today for expert consultation and experience the DataMan 8072 Series barcode inspection system, a leading solution for modern industrial applications.
