Spiral Conveyor – X85 FlexLink
The X85 FlexLink spiral conveyor is an ideal solution for industries that require continuous conveying in limited spaces, such as food processing, pharmaceuticals, logistics, packaging, and fast-moving consumer goods (FMCG).
1. GENERAL OVERVIEW
In modern automation systems, the X85 FlexLink spiral conveyor stands out as an intelligent conveying solution that optimizes floor space and enhances operational efficiency. Featuring an upward or downward spiral design, this conveyor system enables continuous and flexible product movement, making it ideal for facilities with limited space or multi-level production requirements.
2. KEY ADVANTAGES
- Compact design – space saving
With a diameter of only 585 mm, the X85 FlexLink spiral conveyor can be easily integrated into existing production lines without major layout modifications - Vertical space optimization
Capable of elevating or lowering products by up to 2,900 mm, the system maximizes vertical space utilization while maintaining continuous product flow - Modular structure – flexible configuration
The modular design allows easy customization to meet specific production requirements. The system supports multiple chain types, including friction top chains, flat top friction chains, and grooved chains - Smooth operation – low noise level
Thanks to ultra-durable, low-friction slide rails, the X85 conveyor operates smoothly with a noise level of only 73 dB at 50 m/min, creating a more comfortable working environment - Fast installation – long service life
The system can be installed within just a few hours, offering high stability, easy maintenance, and long-lasting performance
3. TECHNICAL SPECIFICATIONS
| Specification | Detail |
| Maximum Load Capacity | 2 kg/m (depending on elevation height) |
| Conveying Speed | 10, 20, 30, 40, 50 m/min |
| Noise Level | 73 dB at a speed of 50 m/min |
| System Diameter | 585 mm |
| Maximum Lifting / Lowering Height | 2900 mm |
| Motor Configuration | Dual-End Drive Motor |
| Chain Type | Standard chain or steel ball chain, 85 mm wide |
SEE DETAILS OF THE X85 FLEXLINK SPIRAL CONVEYOR HERE:
4. APPLICATIONS
The X85 FlexLink spiral conveyor is an ideal solution for industries that require continuous conveying in limited spaces, such as food processing, pharmaceuticals, logistics, packaging, and fast-moving consumer goods (FMCG). With its compact design, gentle product handling, and high flexibility, the X85 FlexLink delivers a superior conveying solution, helping optimize production workflows and reduce facility space costs.
